The high torque provides plenty of power for any job you might be doing on site, allowing you to work faster and more efficiently.
TRANSPORT
WEIGHT
4271
kg
HEIGHT TO
BUCKET PIN
3117
mm
TOTAL WIDTH
WITH WIDE TRACKS
1750
mm
ENGINE
OUTPUT
56.4
kW
EASY TO USE, POWERFUL AND ULTRA RELIABLE
The SVL75-3 is everything you’d expect from a Kubota. An advanced hydraulic system, unique safety and productivity features and innovative technology combine in a machine that’s as powerful as it is desirable.
NEW KUBOTA ENGINE
PERFORMANT HYDRAULIC SYSTEM
The hydraulic system features an innovative advanced multifunction valve that ensures smooth operation of all hydraulic functions when they are activated simultaneously.
The electronic torque management system allows you to work faster and with more power. The ECU constantly monitors the load on the machine to optimise the flow of the hydraulic pump according to the load, preventing engine stalling and ensuring smoother operation, even in difficult conditions.
The High Flow function, delivering 112 l/min, increases hydraulic power for attachments requiring higher flow rates.
SUPERIOR COMFORT
Spacious cab, advanced ergonomics, air conditioning as standard for comfortable working in the most demanding conditions.
EXCELLENT HANDLING
The arm kinematics are optimally designed for a bucket pin height of 3117 mm, making it easy to dump into any container or truck.
The self-levelling function keeps the bucket or fork in a horizontal position without having to manually adjust the angle during lifting. It can be activated or deactivated at the click of a button.
HIGHLY PRODUCTIVE
Shift from low speed at 9.0 km/h to high speed at 13.7 km/h to get the job done faster
The Auto Shift system automatically shifts from high to low speed when cornering for smooth travel.
Operators can now change the sensitivity of the track response using the new LCD display. The SVL75-3 offers three response settings: Soft, Normal and Fast.
TECHNOLOGY
The SVL75-3’s digital colour LCD touchscreen builds on the success of Kubota’s Intelligent Control System to keep you always informed of operating status.
The standard reversing camera provides better rear visibility on the job site.
The engine can be started by entering a 4-digit code on the touchscreen.
Our new integrated Bluetooth radio allows smooth broadcasting and hands-free calling.
SVL75-3
Performance and technical specifications
| Model | SVL75-3 |
|---|---|
| Machine weight (kg) | 4271 |
| Power (ISO 14396:2002) (kW (hp) / rpm) | 54,6 (74,2) / 2400 |
| Max. speed (km/h) slow / fast | 9 / 13,7 |
| Breakout force, bucket / lift arm (kg) | 2710 / 2133 |
| AUX auxiliary circuit (standard flow, l/min) | 72,7 |
| AUX auxiliary circuit (high flow, l/min) | 112,8 |
| Machine width Standard tracks / Wide tracks (mm) | (L) 1675 / 1755 |
| Bucket pin height at max. lift (mm) | (F) 3117 |
| Reach at max. lift and unload (mm) | (H) 1041 |
| Length with bucket on ground (mm) | (D) 3645 |
